KiCad 2011-07-08

KiCad is a free program dedicated to creating schematics of electronic components or printed circuits. It's what's used to design circuit boards.

This program incorporates the necessary components to create this type of circuits and you will only have to drag and drop components on the scheme.

With KiCad you have the following functions:
- Kicad: with which you can manage your projects
- Eeschema: is the appropriate tool for creating schemas
- PcbNew: once the scheme is designed you can go to this tool with which you will create printed circuits
- Gerbview: visualization of documents generated in GERBER format
- Cvpcb: utility of selection of the physical fingerprints of the electronic components used in the scheme
